CuNi6 NC010

Short Description:

牌号TYPE CuNi1 CuNi2 CuNi4 CuNi6 CuNi8 CuMn3 NC003 NC005 NC007 NC010 NC012 NC012 Cu铜 Rest余 Rest余 Rest余 Rest余 Rest余 Rest余成分 Mn锰 – – – – – 3 Composition(%) Ni镍 1 2 4 6 8 最高使用温度 Max.continuous operating 200 200 200 220 250 200 temperatureC 电阻率μΩ ·m(20℃) Resistivity 0.03 ±10% 0.05 ±10% 0.07 ±10% 0.10 ±10% 0.12 ±10% 0.12 ±10% 电阻温度系数×105/℃ (20-600℃) Resistance-temperature coefficient ...

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Port: Shenzhen

Payment Terms: L/C,D/A,D/P,T/T

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

牌号TYPE		CuNi1	CuNi2	CuNi4	CuNi6	CuNi8	CuMn3
牌号TYPE		NC003	NC005	NC007	NC010	NC012	NC012
	Cu铜	Rest余	Rest余	Rest余	Rest余	Rest余	Rest余
成分	Mn锰	–	–	–	–	–	3
Composition(%)	Ni镍	1	2	4	6	8
最高使用温度
Max.continuous operating		200	200	200	220	250	200
temperatureC
电阻率μΩ ·m(20℃) Resistivity		0.03 ±10%	0.05 ±10%	0.07 ±10%	0.10 ±10%	0.12 ±10%	0.12 ±10%
电阻温度系数×105/℃
(20-600℃)
Resistance-temperature coefficient		<100	<120	< 50	<60	<57	<38
对铜热电动势
Thermovoltage to copper at 20℃ in μV/K		-8	-12	-12	-18	-22	工
线均热膨胀系数
Mean coefficient of linear thermal expansion,in 10/K, at a temperature between 20
℃ and 400 ℃		17.5	17.5	17.5	17.5	17.5	18
导电系数
Thermal conductance at 20℃ W/mK		145	130	130	92	75	84
比热
Specific heat capacity at 20℃ J/gK		0.38	0.38	0.38	0.38	0.38	0.39
密度		8.9	8.9	8.9	8.9	8.9	8.8
Density at 20℃(g/cm³)		8.9	8.9	8.9	8.9	8.9	8.8
熔点		1085	1090	1090	1095	1097	1050
Melting temperature in℃		1085	1090	1090	1095	1097	1050
抗拉强度		210	220	220	250	270	290
Min.tensile strength in N/mm²		210	220	220	250	270	290
延伸率%		25	25	25	25	25	25
Elongation		25	25	25	25	25	25
材料名称		铜镍1	铜镍2	铜镍4	铜镍6	铜镍8	铜锰3
材料名称		CN3W	CN5W	CN7W	CN10W	CN12W
