Haynes242 Alloy

Haynes242 (UNS N10242) is an age – hardenable nickel – molybdenum – chromium alloy, engineered to meet the stringent demands of high – temperature applications. This alloy stands out due to its unique combination of properties, making it a preferred choice across multiple industries.

1. Chemical Composition (Mass Fraction, %)

2. Physical Properties

• Density: 0.327 lb/in³ (9.05 g/cm³). This density is relatively high, which is typical for nickel – based superalloys. While it may be a consideration in applications where weight is a critical factor, the alloy’s exceptional performance in high – temperature environments often compensates for the higher density. For example, in aerospace applications where every gram matters, the superior mechanical and thermal properties of Haynes242 may still make it a viable choice despite its weight.
• Melting Range: 2350 – 2550 °F (1288 – 1400 °C). The relatively wide melting range provides some flexibility during casting and welding processes. However, precise temperature control is still crucial to ensure the integrity of the alloy. During casting, the ability to work within this temperature range allows for the production of complex – shaped components with good dimensional accuracy. In welding, proper temperature management within the melting range helps to create strong and reliable joints without compromising the alloy’s properties.
• Elastic Modulus: At room temperature, it has a certain value (to be specified accurately). The elastic modulus indicates the alloy’s stiffness and its ability to resist elastic deformation under an applied load. A high elastic modulus in Haynes242 means that it can maintain its shape well under mechanical stress, which is important for applications where dimensional stability is required, such as in gas turbine components.
• Coefficient of Thermal Expansion: Haynes242 exhibits significantly lower thermal expansion characteristics than most nickel – base high – temperature alloys in the range from room temperature to 1600 °F (871 °C). Although its expansion is greater than that of alloy 909 below 1000 °F (538 °C), at higher temperatures, the difference narrows considerably. This low coefficient of thermal expansion is highly beneficial as it reduces thermal stress during heating and cooling cycles. In applications where the alloy is subjected to repeated temperature changes, such as in industrial furnaces or heat exchangers, the reduced thermal stress helps to prevent cracking and improve the alloy’s long – term reliability.
• Resistivity: [Provide the resistivity value]. This electrical property is relevant in applications where electrical conductivity or resistance to electrical current is a factor. For example, in some electrical heating elements or in applications where electromagnetic interference needs to be controlled, the resistivity of Haynes242 can play a role in determining its suitability.
• Thermal Conductivity: [Specify the value at a specific temperature]. The alloy has sufficient thermal conductivity to dissipate heat effectively in high – temperature applications without overheating. This property is important in heat – transfer applications such as heat exchangers, where the alloy needs to transfer heat efficiently between different fluids while maintaining its structural integrity.
• Outstanding High – Temperature Strength: Haynes242 derives its strength from a unique long – range ordering reaction upon aging. This results in tensile and creep strength properties up to 1200 – 1300 °F (649 – 704 °C) that are as much as double those of solid – solution – strengthened alloys, while still maintaining high ductility in the aged condition. In applications where components are subjected to high mechanical loads at elevated temperatures, such as in gas turbine engines, the alloy’s high – temperature strength ensures reliable operation and long service life.
• Exceptional Oxidation Resistance: It has very good oxidation resistance up to 1500 °F (816 °C). The formation of a stable oxide layer on the alloy’s surface protects it from further oxidation and degradation in oxidizing environments. This makes Haynes242 suitable for use in industrial furnaces, where it can withstand the hot, oxygen – rich atmosphere without significant loss of performance over time.
• Superior Fluoride and Fluorine Resistance: The alloy displays excellent resistance to high – temperature fluorine and fluoride environments. This property makes it an ideal choice for applications in the chemical process industry, particularly in processes involving high – temperature hydrofluoric acid vapor or high – temperature fluoride salt mixtures. For example, in fluoroelastomer process equipment like extrusion screws, Haynes242 can resist the corrosive effects of fluorine – containing substances, ensuring the equipment’s durability and efficient operation.
• Good Low – Cycle Fatigue Properties: Haynes242 has excellent low – cycle fatigue properties, which are crucial in applications where the material is subjected to repeated cyclic loading. In gas turbine components that experience frequent start – stop cycles, the alloy’s ability to withstand these cyclic stresses without cracking or failing is essential for the reliable operation of the turbine.
• High Thermal Stability: It exhibits very good thermal stability, meaning it can maintain its mechanical and chemical properties over long periods at high temperatures. This property is beneficial in applications such as aerospace components that are exposed to extreme heat during flight and need to perform consistently without degradation.

3. Performance Characteristics

4. Production Standards

Haynes242 is produced in accordance with industry – recognized standards such as ASTM B573 and PS – 6085 – 4 Class A for bar products. These standards ensure the quality and consistency of the alloy, covering aspects such as chemical composition limits, mechanical property requirements, and testing procedures. By adhering to these standards, manufacturers can guarantee that Haynes242 meets the strict requirements of various applications, from aerospace to chemical processing.

5. Application Fields

• Aerospace and Gas Turbine Industries:

◦ Seal Rings and Containment Rings: Haynes242′s high – temperature strength, good oxidation resistance, and low thermal expansion make it ideal for seal rings and containment rings in gas turbines. These components need to maintain a tight seal and structural integrity under high – temperature and high – pressure conditions. The alloy’s ability to resist creep and fatigue ensures that the rings do not deform or fail over time, contributing to the efficient and reliable operation of the gas turbine.

◦ Duct Segments and Casings: In gas turbine engines, duct segments and casings are exposed to hot gases. Haynes242′s excellent oxidation resistance and high – temperature strength allow these components to withstand the harsh environment without significant degradation. The alloy’s dimensional stability, due to its low thermal expansion, also helps in maintaining proper clearances between components, ensuring smooth operation of the engine.

◦ Fasteners: Fasteners in aerospace and gas turbine applications need to hold components together firmly under extreme conditions. Haynes242′s high – temperature strength and good corrosion resistance make it suitable for use as fasteners. It can withstand the high – temperature and high – stress environments, preventing loosening or failure of the fasteners, which could have catastrophic consequences for the engine’s performance.

• Chemical Process Industry:

◦ High – Temperature Hydrofluoric Acid Vapor – Containing Processes: Due to its outstanding resistance to high – temperature hydrofluoric acid vapor, Haynes242 is used in chemical processes involving this corrosive substance. For example, in the production of certain fluorinated chemicals, the alloy can be used to construct reaction vessels, pipes, and valves that come into contact with hydrofluoric acid vapor at high temperatures. Its resistance to corrosion ensures the integrity of the equipment and prevents leaks, which could be dangerous and environmentally harmful.

◦ Fluoroelastomer Process Equipment: In fluoroelastomer manufacturing, extrusion screws and other equipment components are exposed to high – temperature fluorine – containing environments. Haynes242′s high strength and resistance to fluorine – based corrosion make it an excellent choice for these applications. The alloy can withstand the abrasive and corrosive forces during the extrusion process, extending the lifespan of the equipment and reducing maintenance costs.

• Other High – Temperature Applications:

◦ Rocket Nozzles: Rocket nozzles experience extremely high temperatures and mechanical stresses during rocket launches. Haynes242′s high – temperature strength, oxidation resistance, and ability to withstand rapid heating and cooling cycles make it a suitable material for rocket nozzle construction. The alloy can maintain its structural integrity under the harsh conditions of rocket propulsion, ensuring efficient thrust generation.

◦ Heat Exchangers: In high – temperature heat exchanger applications, Haynes242 can transfer heat effectively while resisting corrosion and degradation in the hot fluid environment. Its good thermal conductivity and high – temperature resistance allow for efficient heat transfer between different fluids, while its corrosion resistance ensures the long – term durability of the heat exchanger. This is important in various industries, such as power generation and chemical processing, where heat exchangers are used to optimize energy usage and process efficiency.

6. Processing Considerations

• Hot Working: The alloy can be hot worked within a specific temperature range. Heating the workpiece to the appropriate temperature is crucial, and factors such as the size and complexity of the part need to be considered. For complex – shaped components, pre – equilibrating at an intermediate temperature before reaching the final hot – working temperature can be beneficial. It is important to work the alloy quickly with sufficient deformation to maintain heat within the workpiece. This helps to ensure proper grain flow and uniform deformation, resulting in improved mechanical properties.
• Cold Working: Cold working operations such as cold rolling and stamping can be carried out on Haynes242. However, care must be taken to avoid excessive strain, as this can lead to cracking or reduced ductility. Intermediate annealing may be necessary to restore ductility and relieve internal stresses generated during cold working. Annealing helps to recrystallize the alloy’s microstructure, improving its formability and allowing for further cold working if required.
• Welding: Haynes242 has good weldability. However, appropriate filler materials and welding procedures should be selected to ensure the integrity of the welded joint. Extended time at intermediate age – hardening temperatures should be avoided, as this can cause undesirable changes in the alloy’s microstructure and mechanical properties. After welding, post – weld heat treatment may be required to relieve stress and optimize the performance of the joint. The heat treatment process typically involves solution annealing followed by rapid cooling to achieve the desired combination of strength and ductility.
• Heat Treatment: The alloy can be solution – annealed at 2012 °F (1100 °C) followed by rapid cooling to restore its optimal properties. This heat treatment process helps to dissolve any precipitates and homogenize the alloy’s microstructure. For age – hardening, specific temperature and time schedules are applied to enhance the alloy’s strength through the long – range ordering reaction. The age – hardening treatment is carefully controlled to achieve the desired balance of strength, ductility, and other properties required for the intended application.

In summary, Haynes242 is a high – performance alloy that offers a unique combination of properties, making it well – suited for a wide range of high – temperature applications. Its excellent high – temperature strength, oxidation resistance, and resistance to fluorine – containing environments, along with good fabricability, make it a valuable material in industries where reliability and durability under extreme conditions are of utmost importance.
