    Inconel 625LCF™ is specifically designed with low cycle fatigue resistance at temperatures up to 649°C (1200°F).

    The following datasheet will provide more details about Inconel 625LCF™.

    Chemical Composition

    The following table shows the chemical composition of Inconel 625LCF™.

    Element Content (%)
    Nickel, Ni ≥ 58
    Chromium, Cr 20-23
    Molybdenum, Mo 8-10
    Iron, Fe ≤ 5
    Niobium, Nb 3.15 – 4.15
    Cobalt, Co ≤ 1
    Manganese, Mn ≤ 0.50
    Titanium, Ti ≤ 0.40
    Aluminum, Al ≤ 0.40
    Carbon, C ≤ 0.030
    Nitrogen, N ≤ 0.020
    Silicon, Si ≤ 0.020
    Phosphorous, P ≤ 0.015
    Sulfur, S ≤ 0.015

    Physical Properties

    The physical properties of Inconel 625LCF™ are outlined in the following table.

    Properties Metric Imperial
    Density 8.44 g/cm³ 0.305 lb/in³
    Melting point 1290-1350°C 2350-2460°F

    Mechanical Properties

    The mechanical properties of annealed Inconel 625LCF™ are provided below.

    Properties Metric Imperial
    Tensile strength 769.5 MPa 111600 psi
    Yield strength (at strain 0.200%) 319 MPa 46300 psi
    Elastic modulus 208 GPa 30200 ksi
    Shear modulus 81.4 GPa 11800 ksi
    Poisson’s ratio 0.28 0.28
    Elongation at break 63% 63%
    Hardness, Rockwell B 84 84

    Thermal Properties

    The thermal properties of Inconel 625LCF™ are given below.

    Properties Metric Imperial
    Thermal expansion co-efficient (at 21-100°C/69.8-212°F) 12.8 µm/m°C 7.11 µin/in°F
    Thermal conductivity 9.70W/mK 67.3 BTU in/hr.ft².°F
