    Introduction

    Super alloys or high performance alloys have the capacity to function under very high temperatures and severe mechanical stress, and also where high surface stability is required. They have good creep and oxidation resistance, and can be produced in a variety of shapes.

    Strengthening of super alloys is performed by solid-solution hardening, work hardening, and precipitation hardening. Super alloys contain a number of elements in a variety of combinations to achieve the desired result.

    Inconel 686™ is a single phase Ni-Cr-Mo-W alloy that is primarily used in extremely corrosive applications, e.g. flue gas desulfurization systems and processing plants in which mixed acids are used. This alloy is also used in fields where localized pitting is difficult.

    The following datasheet will provide more details about Inconel 686™.

    Chemical Composition

    The following table shows the chemical composition of Inconel 686™.

    Element Content (%)
    Nickel, Ni 59
    Chromium, Cr 19-23
    Molybdenum, Mo 15-17
    Iron, Fe ≤ 5
    Tungsten, W 3.0-4.40
    Manganese, Mn ≤ 0.75
    Phosphorous, P ≤ 0.040
    Sulfur, S ≤ 0.020
    Titanium, Ti 0.020-0.25
    Carbon, C ≤ 0.010

    Physical Properties

    The physical properties of Inconel 686™ are outlined in the following table.

    Properties Metric Imperial
    Density 8.72 g/cm³ 0.315 lb/in³
    Melting point 1338-1380 °C 2440-2520 °F

    Mechanical Properties

    The mechanical properties of Inconel 686™ are provided below.

    Properties Metric Imperial
    Tensile strength 721.9 MPa 104700 psi
    Yield strength (@strain 0.200%) 364 MPa 52800 psi
    Elastic modulus 207 GPa 30000 ksi
    Shear modulus 77 GPa 11200 ksi
    Poisson’s ratio 0.34 0.34
    Elongation at break 71% 71%

    Thermal Properties

    The thermal properties of Inconel 686™ are given below.

    Properties Metric Imperial
    Thermal expansion co-efficient (@21-100°C/69.8-212°F) 11.97 µm/m°C 6.650 µin/in°F
