CuNi19 NC025

Short Description:

牌号TYPE CuNi10 CuNi14 CuNi19 CuNi23 CuNi30 CuNi34 CuNi44 NC015 NC020 NC025 NC030 NC035 NC040 NC050 Cu铜 Rest余 Rest余 Rest余 Rest余 Rest余 Rest余 Rest余成分 Mn锰 – 0.3 0.5 0.5 1 1 1 Composition(%) Ni镍 10 14.2 19 23 30 34 44 最高使用温度 Max.continuous operating 250 300 300 300 350 350 400 temperatureC 电阻率μΩ ·m(20℃) Resistivity 0.15 ±10% 0.20 ±5% 0.25 ±5% 0.30 ±5% 0.35 ±5% 0.40 ±5% 0.49 ±5% 电阻温度系数×105/℃ (20-600℃) ...

FOB Price: US $0.5 - 9,999 / Piece

Min.Order Quantity: 100 Piece/Pieces

Supply Ability: 10000 Piece/Pieces per Month

Port: Shenzhen

Payment Terms: L/C,D/A,D/P,T/T

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

牌号TYPE		CuNi10	CuNi14	CuNi19	CuNi23	CuNi30	CuNi34	CuNi44
牌号TYPE		NC015	NC020	NC025	NC030	NC035	NC040	NC050
	Cu铜	Rest余	Rest余	Rest余	Rest余	Rest余	Rest余	Rest余
成分	Mn锰	–	0.3	0.5	0.5	1	1	1
Composition(%)	Ni镍	10	14.2	19	23	30	34	44
最高使用温度
Max.continuous operating		250	300	300	300	350	350	400
temperatureC
电阻率μΩ ·m(20℃) Resistivity		0.15 ±10%	0.20 ±5%	0.25 ±5%	0.30 ±5%	0.35 ±5%	0.40 ±5%	0.49 ±5%
电阻温度系数×105/℃
(20-600℃)
Resistance-temperature coefficient		<50	<38	<25	<16	<10	<-0	<-6
对铜热电动势
Thermovoltage to copper at 20℃ in μV/K		-25	-28	-32	-34	-37	-39	-43
线均热膨胀系数
Mean coefficient of linear thermal expansion,in 10/K, at a temperature between 20
℃ and 400 ℃		17.5	17.5	17.5	17.5	17	16	15
导电系数
Thermal conductance at 20℃ W/mK		59	48	38	33	27	25	23
比热
Specific heat capacity at 20℃ J/gK		0.38	0.38	0.38	0.38	0.39	0.4	0.41
密度		8.9	8.9	8.9	8.9	8.9	8.9	8.9
Density at 20℃(g/cm³)		8.9	8.9	8.9	8.9	8.9	8.9	8.9
熔点		1100	1115	1135	1150	1170	1180	1280
Melting temperature in℃		1100	1115	1135	1150	1170	1180	1280
抗拉强度		290	310	340	350	400	400	420
Min.tensile strength in N/mm²		290	310	340	350	400	400	420
延伸率%		25	25	25	25	25	25	25
Elongation		25	25	25	25	25	25	25
材料名称		铜镍10	铜镍14	铜镍19	铜镍23	铜镍30	铜镍34	铜镍44
材料名称		CN15W	CN20W	CN25W	CN30W	CN35W	CN40W	CN50W
